NSS60601MZ4 - NPN Transistor

NSS60601MZ4 60 V, 6.0 A, Low VCE(sat) NPN Transistor ON Semiconductor’s e2PowerEdge family of low VCE(sat) transistors are surface mount devices featuring ultra low saturation voltage (VCE(sat)) and high current gain capability. These are designed for use in low voltage, high speed switching applications where affordable efficient energy control is important. Typical applications are DC DC converters and power management in portable and battery powered products such as cellular and cord.

NSS60601MZ4 Features

* NSV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC

* Q101 Qualified and PPAP Capable

* These Devices are Pb

* Free, Halogen Free/BFR Free and are RoHS Compliant

* Complementary to NSS60600MZ4 MAXIMUM
