NXV08H300DT1 Automotive Power MOSFET

Pin No. 1 Q2 Gate 2 Q2 Source Sense 3 B+ #2 Sense 4 Q4 Gate 5 Q4 Source Sense 6 NTC1 7 Phase Out2 8 Phase Out1 9 NTC2 10 Q3 Source Sense 11 Q3 Gate 12 B+ #1 Sense 13 Q1 Source Sense 14 Q1 Gate 15 B+ #1 16 GND 17 B+ #2 Description Remark For 3 phase motor inverter.

NXV08H300DT1 Features

* 2 Phase MOSFET Module At Customer Side this Module Can Be Used as 1/2 Bridge MOSFET Module by Combining 2 Phase Out Power Terminals

* Electrically Isolated DBC Substrate for Low Rthjc

* Compact Design for Low Total Module Resistance

* Module Serialization for Full T
