SA28A, SA20A Datasheet - ON Semiconductor

SA28A 500 Watt Peak Power Zener Transient Voltage Suppressors

SA5.0A Series 500 Watt Peak Power MiniMOSORBt Zener Transient Voltage Suppressors Unidirectional The SA5.0A series is designed to protect voltage sensitive components from high voltage, high energy transients. They have excellent clamping capability, high surge capability, low zener impedance and fast response time. The SA5.0A series is supplied in ON Semiconductor's exclusive, cost‐effective, highly reliable Surmetict axial leaded package and is ideally‐suited for use in communication systems, .

SA28A Features

* ăWorking Peak Reverse Voltage Range - 5.0 to 170 V

* ăPeak Power - 500 Watts @ 1.0 ms

* ăESD Rating of Class 3 (>16 kV) per Human Body Model

* ăMaximum Clamp Voltage @ Peak Pulse Current

* ăLow Leakage < 1 mA above 8.5 V

* ăUL 497B for Isolated Loop Circui

SA20A-ONSemiconductor.pdf

This datasheet PDF includes multiple part numbers: SA28A, SA20A. Please refer to the document for exact specifications by model.
SA28A Datasheet Preview Page 2 SA28A Datasheet Preview Page 3

Datasheet Details

Part number:

SA28A, SA20A

Manufacturer:

ON Semiconductor ↗

File Size:

67.57 KB

Description:

500 watt peak power zener transient voltage suppressors.

Note:

This datasheet PDF includes multiple part numbers: SA28A, SA20A.
Please refer to the document for exact specifications by model.
