VN0610LL
VN0610LL is FET Transistor manufactured by onsemi.
FET Transistor
N- Channel
- Enhancement
MAXIMUM RATINGS
Rating
Drain
- Source Voltage
Drain
- Gate Voltage (RGS = 1 MΩ)
Gate
- Source Voltage
- Continuous
- Non- repetitive (tp ≤ 50 μs)
Drain Current Continuous Pulsed
Total Power Dissipation @ TA = 25°C Derate above 25°C
Operating and Storage Temperature Range
THERMAL CHARACTERISTICS
Characteristics
Thermal Resistance, Junction to Ambient
Maximum Lead Temperature for Soldering Purposes, 1/16” from case for 10 seconds
Symbol VDSS VDGR
Value 60 60
Unit Vdc Vdc
VGS VGSM
ID IDM PD
TJ, Tstg
± 20 ± 40
190 1000 400 3.2
- 55 to +150
Vdc Vpk m Adc m W m W/°C
°C
Symbol RθJA
Max 312.5
Unit °C/W
°C http://onsemi.
1 23
CASE 29- 11, STYLE 22 TO- 92 (TO- 226AA) 3 DRAIN 2 GATE 1 SOURCE
