MJE122 - Complementary Silicon Power Transistors

MJE122 Description

MOTOROLA SEMICONDUCTOR TECHNICAL DATA Order this document by MF122/D Complementary Power Darlingtons * * * *

MJE122 Applications

* Designed for general
* purpose amplifiers and switching applications, where the mounting surface of the device is required to be electrically isolated from the heatsink or chassis. Electrically Similar to the Popular TIP122 and TIP127 100 VCEO(sus) 5 A Rated Collector Current No Isolating Wash

📥 Download Datasheet

Preview of MJE122 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
MJE122
Manufacturer
ON
File Size
267.36 KB
Datasheet
MJE122_ONSemiconductor.pdf
Description
Complementary Silicon Power Transistors
