Description
The OR-10XX series devices consist of an infrared emitting diode, optically coupled to a photo transistor detector.They are packaged in a 4-pin SOP package.
Features
- (1) Current transfer ratio：(CTR: 50~600% at IF = 5mA, VCE = 5V) (CTR: 63~320% at IF = 10mA, VCE = 5V)
(2) High input-output isolation voltage ( Viso = 5,000Vrms ) (3) High collector-emitter voltage ( VCEO = 80V ) (4) Temperature range -55 ℃ to 125℃ (5) Creepage distance > 8mm (6) Employs double transfer mold technology (7) Long Mini-flat package : 2.3mm profile :OR-10XX series (8) ESD pass HBM 8000V/MM 2000V (9) Safety approval
UL approved(No. E323844) VDE approved(No.40029733) CQC approved (No. C.
