MBR3040CT, MBR3020CT - SCHOTTKY BARRIER RECTIFIER

MBR3040CT Description

MBR3020CT~MBR30100CT SCHOTTKY BARRIER RECTIFIERS VOLTAGE .

MBR3040CT Features

* Plastic package has Underwriters Laboratory Flammability Classification 94V-O. Flame Retardant Epoxy Molding Compound.
* Exceeds environmental standards of MIL-S-19500/228
* Low power loss, high efficiency.
* Low forwrd voltge, high current capability
* High

MBR3040CT Applications

* In compliance with EU RoHS 2002/95/EC directives .50(12.7)MIN .419(10.66) .387(9.85) .139(3.55) MIN 20 to 100 Volts CURRENT 30.0 Amperes TO-220AB Unit : inch (mm) .196(5.00) .163(4.16) .054(1.39) .045(1.15) .269(6.85) .226(5.75) .624(15.87) MECHANICAL DA TA
* Case: TO-220A

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: MBR3040CT, MBR3020CT. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
MBR3040CT, MBR3020CT
Manufacturer
Pan Jit International
File Size
129.24 KB
Datasheet
MBR3020CT-PanJitInternational.pdf
Description
SCHOTTKY BARRIER RECTIFIER
Note
This datasheet PDF includes multiple part numbers: MBR3040CT, MBR3020CT.
Please refer to the document for exact specifications by model.
