LNJ212R8ARA Datasheet - Panasonic Semiconductor

LNJ212R8ARA Surface Mounting Chip LED

Light Emitting Diodes This product complies with the RoHS Directive (EU 2002/95/EC). LNJ212R8ARA Surface Mounting Chip LED TSS Type Absolute Maximum Ratings Ta = 25°C Power dissipation PD Forward current IF Pulse forward current IFP Reverse voltage VR Operating ambient temperature Topr Storage temperature Tstg Note) : The condition of IFP is duty 10%, Pulse width 1 msec. 50 20 60 3 30 to +85 40 to +100 mW mA mA V °C °C Lighting Col.

LNJ212R8ARA_PanasonicSemiconductor.pdf

Preview of LNJ212R8ARA PDF
LNJ212R8ARA Datasheet Preview Page 2 LNJ212R8ARA Datasheet Preview Page 3

Datasheet Details

Part number:

LNJ212R8ARA

Manufacturer:

Panasonic Semiconductor

File Size:

341.25 KB

Description:

Surface mounting chip led.
