A2064 - 2SA2064

Product Overview

Panasonic

Part number	A2064
Manufacturer	Panasonic
File Size	220.17 KB
Description	2SA2064
Datasheet	A2064 Datasheet
Additional preview pages of the A2064 datasheet.

>.
High speed switching (tstg: storage time/tf: fall time is short).
Low collector-emitter saturation voltage VCE(sat).
Superior forward current transfer ratio hFE linearity.
TO-220D built-in: Excellent package with withstand voltage 5 kV guaranteed.
Absolute Maximum Ratings TC = 25°C Parameter Symbol Rating Collector-base voltage (Emitter open) Collector-emitter voltage (Base open) Emitter-base voltage (Collector open) Collector current Peak collector cur.
