JQ1-12V-F Features
* High electrical noise immunity
* High switching capacity in a compact package
* High sensitivity: 200 mW (1a), 400 mW (1c)
* High surge voltage: 8,000 V between contacts and coil
* UL, CSA, VDE, SEMKO approved and TÜV available
* Class B coil insulat
Datasheet Details
JQ1-12V-F, JQ1a-5V-F
Panasonic
520.38 KB
1a/1c 5a/10a small power relays.
This datasheet PDF includes multiple part numbers: JQ1-12V-F, JQ1a-5V-F.
Please refer to the document for exact specifications by model.
