MA4180

Silicon planar type

MA4180 Features

* High reliability, achieved by the DHD structure

* Allowing to insert to a 5 mm pitch hole

* Finely divided zener-voltage rank

* Sharp rising performance

* Wide voltage range: VZ = 2.0 V to 39 V φ 0.45 max. 1 13 min. Colored band indicates Vz classification

MA4180 Datasheet (76.66 KB)

Preview of MA4180 PDF

Datasheet Details

Part number:

MA4180

Manufacturer:

Panasonic

File Size:

76.66 KB

Description:

Silicon planar type.
