Part number:
MAZ8051
Manufacturer:
Panasonic
File Size:
69.49 KB
Description:
Silicon planar type.
Rating:
1
★
(3 votes)
* Extremely low noise voltage caused from the diode (2.4V to 39V, 1/3 to 1/10 of our conventional MAZ3000 series)
* Extremely good rising performance (in the low-current range)
* Easy-to-select the optimum diode because of their finely divided zener-voltage ranks
* Gu
MAZ8051
Panasonic
69.49 KB
Silicon planar type.
