74HC237 Datasheet, Decoder/demultiplexer, Philips

74HC237 Features

• Decoder/demultiplexer
• Combines 3-to-8 decoder with 3-bit latch
• Multiple input enable for easy expansion or independent controls
• Active HIGH mutually exclusive outputs

PDF File Details

Part number:

74HC237

Manufacturer:

Philips

File Size:

68.33kb

Download:

📄 Datasheet

Description:

3-to-8 line decoder/demultiplexer. The 74HC/HCT237 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL). They are specified in

74HC237 Application

• Applications in bus oriented systems. QUICK REFERENCE DATA GND = 0 V; Tamb = 25 °C; tr = tf = 6 ns TYPICAL SYMBOL tPHL / tPLH PARAMETER propagation
