LCM128642 - LCM Module
) Ground for Logic() Power supply for Logic() Power supply for LCD drive() Register selection(、) Read/Write selection() Enable signal for LCM() Data Bus lines( 0~7) Chip select signal() Chip select signal() Reset Signal() Negative voltage output() Power supply for Backlight (+)() Power supply for Ba
LCM128642 Features
* Item Module Size (W
* H
* T) Normal Dimensions (mm) 113x65x13 Feature LCD Type & Colour STN:Yellow-Green STN View Area (W
* H) 73.4x38.8 View Angle 6 O’clock 6:00 Dots x Dots (W
* H) 128x64 Display Type Positive Type Dot Size (W
* H) 0.458x0.458 Control IC & Pack
