DTC143ZKAFRA - NPN 100mA 50V Digital Transistors

Product Overview

ROHM

Part number	DTC143ZKAFRA
Manufacturer	ROHM
File Size	1.28 MB
Description	NPN 100mA 50V Digital Transistors
Datasheet	DTC143ZKAFRA Datasheet
Additional preview pages of the DTC143ZKAFRA datasheet.

lInner circuit d 1) Built-In Biasing Resistors e 2) Built-in bias resistors enable the configuration of 　an inverter circuit without connecting external d 　input resistors (see inner circuit) . n s 3) The bias resistors consist of thin-film resistors 　with complete isolation to allow negative biasing e n of the input. They also have the advantage of 　completely eliminating parasitic effects. m ig 4) Only the on/off conditions need to be set 　for operation, making the circuit design ea.
