RS8802 - Low-Side Gate Driver

RUNIC

📥 Download Datasheet

RS8802 Datasheet Preview — Preview of RS8802 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	RS8802
Manufacturer	RUNIC
File Size	445.47 KB
Description	Low-Side Gate Driver
Datasheet	RS8802-RUNIC.pdf

RS8802 Product details

Description

The RS8802 dual-channel, high-speed, low-side gate driver device is capable of effectively driving MOSFET and IGBT power switches.

Features

Industry-Standard Pinout.
Two Independent Gate-Drive Channels.
5A Peak Source and Sink-Drive Current.
TTL and CMOS Compatible Logic Threshold Independent of Supply Voltage.
Hysteretic-Logic Thresholds for High Noise Immunity.
Inputs Pin-Voltage Levels Not Restricted by VDD Pin Bias Supply Voltage.
4.5V to 18V Single-Supply Range.
Outputs Held Low During VDD-UVLO, (Ensures Glitch-Free Operation at Power up and Power Down).
