BR3505 Datasheet - Rectron Semiconductor

SINGLE-PHASE SILICON BRIDGE RECTIFIER

BR3505 Features

* Superior thermal desing 400 amperes surge rating // 1/4 universal faston terminal Hole thru for # 8 screw MECHANICAL DATA

* UL listed the recognized component directory, file #E94233

* Epoxy: Device has UL flammability classification 94V-O BR-35 MAXIMUM RATINGS AND

BR3505 Datasheet (27.61 KB)

Preview of BR3505 PDF

Datasheet Details

Part number:

BR3505

Manufacturer:

RectrON Semiconductor ↗

File Size:

27.61 KB

Description:

Single-phase silicon bridge rectifier.
RECTRON SEMICONDUCTOR TECHNICAL SPECIFICATION BR3505 THRU BR3510 SINGLE-PHASE SILICON BRIDGE RECTIFIER VOLTAGE RANGE 50 to 1000 Volts CURRENT 35 Amp.
