M37221MAH-XXXSP, M37221M8H - (M37221M4H/M8H/M6H/EASP) Single-Chip 8-Bit CMOS Microcomputer

Renesas Technology

M37221MAH-XXXSP Datasheet Preview — This datasheet PDF includes multiple part numbers: M37221MAH-XXXSP, M37221M8H. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	M37221MAH-XXXSP, M37221M8H
Manufacturer	Renesas ↗ Technology
File Size	1.11 MB
Description	(M37221M4H/M8H/M6H/EASP) Single-Chip 8-Bit CMOS Microcomputer
Datasheet	M37221M8H_RenesasTechnology.pdf
Note	This datasheet PDF includes multiple part numbers: M37221MAH-XXXSP, M37221M8H. Please refer to the document for exact specifications by model.

M37221MAH-XXXSP Product details

Description

The M37221M4H/M6H/M8H/MAH-XXXSP/FP are single-chip microcomputers designed with CMOS silicon gate technology. OSD function Display characters 24 characters 5 2 lines (3 lines or more can be displayed by software) Kinds of characters 256 kinds Character display area 12 ✕ 16 dots Kinds of character sizes 3 kinds Kinds

Features

Number of basic instructions 71 size ROM 16K bytes (M37221M4H-XXXSP/FP) 24K bytes (M37221M6H-XXXSP/FP) 32K bytes (M37221M8H-XXXSP/FP) 40K bytes (M37221MAH-XXXSP/FP, M37221EASP/FP) RAM 384 bytes (M37221M4H-XXXSP/FP) 448 bytes (M37221M6H-XXXSP/FP) 576 bytes (M37221M8H-XXXSP/FP) 704 bytes (M37221MAH-XXXSP/FP, M37221EASP/FP) (ROM correction memory included).
The minimum instruction execution time 0.5 µs (at 8 MHz oscillation frequency).
Power source voltage 5 V ± 10 %.
Subrout.
