Part number: RT8800B
Manufacturer: Richtek Technology
File Size: 584.40KB
Download: 📄 Datasheet
Description: General Purpose 2/3-Phase PWM Controller
5V Power Supply Voltage 2/3-Phase Power Conversion with Automatic Phase Selection (RT8800 : 2/3-Phase, RT8800B : 2-Phase) Output Voltage Controlled by External Reference .
Desktop CPU core power Low Output Voltage, High power density DC-DC Converters Voltage Regulator Modules
Note :
RichTek.
The RT8800/B are general purpose multi-phase synchronous buck controllers dedicating for high density power supply regulation. The parts implement 2, and 3 buck switching stages operating in interleaved phase set automatically. The output voltage is .
