BA5415A Datasheet, amplifier equivalent, Rohm

BA5415A Features

• Amplifier 1) High output. POUT = 5.4W (VCC = 12V, RL = 3Ω and THD = 10%) POUT = 2.5W (VCC = 9V, RL = 4Ω and THD = 10%) 2) Excellent audio quality. THD = 0.1% (f = 1kHz, PO = 0.5W) VNO = 0.3mVrms

PDF File Details

Part number:

BA5415A

Manufacturer:

ROHM ↗

File Size:

257.48kb

Download:

📄 Datasheet

Description:

High-output dual power amplifier.

BA5415A Application

• Applications Radio cassette players. FFeatures 1) High output. POUT = 5.4W (VCC = 12V, RL = 3Ω and THD = 10%) POUT = 2.5W (VCC = 9V, RL = 4Ω and THD
