BA5417 - High-output dual power amplifier

Product Overview

Rohm

📥 Download Datasheet

BA5417 High-output dual power amplifier by Rohm - Datasheet Preview — Datasheet preview – BA5417

Datasheet Details

Part number	BA5417
Manufacturer	ROHM
File Size	778.29 KB
Description	High-output dual power amplifier
Datasheet	BA5417 Datasheet
Additional preview pages of the BA5417 datasheet.

Product details

Description

The BA5406/BA5417 is a dual OTL monolithic power IC with two built-in, high output speaker amplifier circuits.

Features

6 1) Good low voltage characteristics (Operation from Vcc=5 V) 2) Ripple filter (6pin) also can be used as muting pin (Make 6pin GND potential) 3) Small thermal resistance package and simple heatsink design BA5417 1) Small pop noise when standby switches ON/OFF 2) Built-in circuit to prevent ripple addition when motor starts 3) Built-in thermal shutdown circuit 4) Built-in standby switch circuit 5) Built-in soft clip circuit.
