BD4153EFV - Power switch for ExpressCard

BD4153EFV Description

Power Management Switch ICs for PCs and Digital Consumer Products Power Switch ICs for ExpressCardTM BD4153FV,BD4153EFV No.10029EBT08 *Descripti.
BD4153FV/EFV is a power management switch IC for the next generation PC card (ExpressCardTM) that PCMCIA recommends.

BD4153EFV Features

* 1) Incorporates three low on-resistance FETs for ExpressCardTM. 2) Incorporates an FET for output discharge. 3) Incorporates an enabler. 4) I Incorporates an undervoltage lockout (UVLO) 5) I Employs SSOP-B24 package. 6) I Employs HTSSOP-B24 package. 7) Incorporates a thermal shutdown protector (TSD)

📥 Download Datasheet

Preview of BD4153EFV PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BD4153EFV
Manufacturer
ROHM ↗
File Size
726.09 KB
Datasheet
BD4153EFV_Rohm.pdf
Description
Power switch for ExpressCard
