RPM5500 Datasheet - Rohm

RPM5500 IR Receiver

Pin No. 1 2 3 4 5 6 7 Pin name VCC GND GND GND ROUT GND GND Function POWER SUPPLY GROUND GROUND GROUND OUTPUT TERMINAL GROUND GROUND zElectrical, Optical characteristics (Unless otherwise noted, Ta = 25°C VCC=5V) Parameter Consumption Current Effective Distance High Level Output Voltage Low Level O.

RPM5500 Features

* 1) Small size, SMD type. 2) Low current consumption. (0.95mA Typ.) 3) High ripple rejection. 4) Top view package type & Side view package type. zRPM5500 series Sub carrier frequency 36.7kHz 37.9kHz 40.0kHz SIDE VIEW RPM5537-H14 RPM5538-H14 RPM5540-H14 TOP VIEW RPM5537-H12 RPM5538-H12 RPM5540-H12 z

RPM5500 Datasheet (140.62 KB)
