MMBZ5253B Datasheet - SEMTECH

MMBZ5253B SILICON PLANAR ZENER DIODES

MMBZ5221B~MMBZ5262B SILICON PLANAR ZENER DIODES 3 12 SOT-23 Plastic Package Absolute Maximum Ratings (Ta = 25 OC) Parameter HPower Dissipation Thermal Resistance, Junction to Ambient Junction Temperature SEMTECStorage Temperature Range Symbol PD RθJA Tj Tstg Value 350 357 150 - 55 to + 150 Unit mW OC/W OC OC SEMTECH ELECTRONICS LTD. Subsidiary of Sino-Tech International (BVI) Limited ® Dated: 21/09/2012 Rev: 01 MMBZ5221B~MMBZ5262B Characteristics Ta = 25 OC (VF = 0.9 V Maximum at IF =.

MMBZ5253B Datasheet (482.30 KB)

Preview of MMBZ5253B PDF
MMBZ5253B Datasheet Preview Page 2 MMBZ5253B Datasheet Preview Page 3

Datasheet Details

Part number:

MMBZ5253B

Manufacturer:

SEMTECH

File Size:

482.30 KB

Description:

Silicon planar zener diodes.
