MMBZ5256B Datasheet - SEMTECH

MMBZ5256B SILICON PLANAR ZENER DIODES

MMBZ5221B~MMBZ5262B SILICON PLANAR ZENER DIODES 3 12 SOT-23 Plastic Package SEMTECH Absolute Maximum Ratings (Ta = 25 OC) Parameter Power Dissipation Thermal Resistance, Junction to Ambient Junction Temperature Storage Temperature Range Symbol PD RθJA Tj Tstg Value 350 357 150 - 55 to + 150 Unit mW OC/W OC OC SEMTECH ELECTRONICS LTD. Subsidiary of Sino-Tech International (BVI) Limited ® Dated: 21/09/2012 Rev: 01 MMBZ5221B~MMBZ5262B Characteristics Ta = 25 OC (VF = 0.9 V Maximum at IF .

MMBZ5256B Datasheet (482.30 KB)

Preview of MMBZ5256B PDF

Datasheet Details

Part number:

MMBZ5256B

Manufacturer:

SEMTECH

File Size:

482.30 KB

Description:

Silicon planar zener diodes.
