SGM3838 Datasheet, Supply, SG Micro

SGM3838 Features

• Supply
• 2.5V to 4.8V Input Supply Voltage Range
• Synchronous Boost Converter (ELVDD)
• 4.6V to 5.0V Output Voltage with 100mV Steps
• 4.6V Default Output Volt

PDF File Details

Part number:

SGM3838

Manufacturer:

SG Micro

File Size:

0.96MB

Download:

📄 Datasheet

Description:

Triple-output 700ma amoled display power supply. The SGM3838 is designed for powering AMOLED displays which require VELVDD, VELVSS and VAVDD. The device integrates two Boost converte

SGM3838 Application

• Applications Smartphones & Tablets Active Matrix OLED Displays TYPICAL APPLICATION VIN = 2.5V to 4.8V 10μF 10μF 10μF 10μF 2.2μH A2, B2 SW1 Boost
