STP3NB80 Datasheet, Mosfet, ST Microelectronics

PDF File Details

Part number:

STP3NB80

Manufacturer:

STMicroelectronics ↗

File Size:

263.43kb

Download:

📄 Datasheet

Description:

N - channel powermesh mosfet. Using the latest high voltage MESH OVERLAY™ process, STMicroelectronics has designed an advanced family of power MOSFETs with outstan

STP3NB80 Application

• Applications HIGH CURRENT, HIGH SPEED SWITCHING s UNINTERRUPTIBLE POWER SUPPLY(UPS) s DC-DC & DC-AC CONVERTERS FOR TELECOM, INDUSTRIAL AND CONSUMER
