BT4730D Datasheet - STMicroelectronics

BT4730D Audio Power Amplifier

The TDA7379 is a new technology class AB audio processor amplifier able to work either in DUAL BRIDGE or QUAD SINGLE ENDED configuration. The exclusive fully complementary structure of the output stage and the internally fixed gain guarantee the highest power performances with extremely reduced comp.
TDA7379 4 X 13 - 2 X 38W AUDIO POWER AMPLIFIER 2 X 13 + 1 X 38W AUDIO POWER AMPLIFIER PRODUCT PREVIEW HIGH OUTPUT POWER CAPABILITY 2 x 38W/4Ω @18V, 1KHz, 10% 4 x 11W/4Ω @18V, 1KHz, 10% 2 x 20W/8Ω @18V; 1KHz, 10% 4 x 13W/2Ω @15V, 1KHz, 10% 2 x 34W/8Ω @ 22V, 1kHz, 10% MINIMUM EXTERNAL COMPONENTS COUNT: NO BOOTSTRAP CAPACITORS NO BOUCHEROT CELLS INTERNALLY FIXED GAIN (26dB BTL) ST-BY FUNCTION (CMOS COMPATIBLE) NO AUDIBLE POP DURING ST-BY OPER.

BT4730D Datasheet (582.30 KB)

Preview of BT4730D PDF
BT4730D Datasheet Preview Page 2 BT4730D Datasheet Preview Page 3

Datasheet Details

Part number:

BT4730D

Manufacturer:

STMicroelectronics ↗

File Size:

582.30 KB

Description:

Audio power amplifier.
