BTA10 Datasheet, Triacs, STMicroelectronics

BTA10 Features

• Triacs
• Medium current Triac
• Low thermal resistance with clip bonding
• Low thermal resistance insulation ceramic for insulated BTA
• High commutation (4Q) o

PDF File Details

Part number:

BTA10

Manufacturer:

STMicroelectronics ↗

File Size:

229.02kb

Download:

📄 Datasheet

Description:

Logic level and standard triacs. Available either in through-hole or surface mount packages, the BTA10, BTB10 and T10xx Triac series are suitable for general purpose

BTA10 Application

• Applications such as static relays, heating regulation or induction motor starting circuit. They are also recommended for phase control operations i
