STN9360 Datasheet - STMicroelectronics

High voltage fast-switching PNP power transistor

STN9360 General Description

This device is a high voltage fast-switching PNP power transistor. It is manufactured using high voltage multi epitaxial planar technology for high switching speeds and medium voltage capability. It uses a cellular emitter structure with planar edge termination to enhance switching speeds while mai.

STN9360 Datasheet (393.95 KB)

Preview of STN9360 PDF

Datasheet Details

Part number:

STN9360

Manufacturer:

STMicroelectronics ↗

File Size:

393.95 KB

Description:

High voltage fast-switching pnp power transistor.
