S3C49F9X - Compact Flash Controller

Product Overview

Samsung semiconductor

Datasheet Details

Part number	S3C49F9X
Manufacturer	Samsung semiconductor
File Size	517.01 KB
Description	Compact Flash Controller
Datasheet	S3C49F9X Datasheet
Additional preview pages of the S3C49F9X datasheet.

Product details

Description

I/O Type I1 I2 I3 I4 I5 I6 I7 O1 O2 www.DataSheet4U.com O3 Pad Type PVIL3 PVILU3 PIS PIC PICU PICD PVILD3 PVOB43 POD4 POB4 POB4SM POB16SM POB12 PVBTT43 PBCT4 PBCT4SM PBCUT4SM PBCT8SM PBCUT8SM PBCDT8 PBSDT4SM PBCT16SM PVBTD43 PSOSCM26 Description 3.3V TTL schmitt trigger level PCMCIA LIN input buffer 3.3V TTL schmitt trigger level PCMCIA LIN input buffer with pull-up register CMOS schmitt trigger level input buffer CMOS level input buffer CMOS level input buffer with pull-up register CMOS level

Features

- PC Card-ATA/True IDE/CompactFlash compatible host interface - Automatic sensing of PC Card ATA and 68-pin IDE - Included 256-byte CIS RAM - Five PC Card ATA addressing modes - Host data transfer rate : 20MB/S - Flash data transfer rate : 10MB/S - Host Interface : 8/16-bit Access - Flash Interface : 8-bit Access - Support 3 power save mode : stop/idle/active - Support up to 10 flash memories - Support 32/64/128/256/512Mbit,1Gbit NAND flash memory made by Samsung NAND Flash Density 32Mb, 64Mb, 1.
