S524A40X40 - 1K/2K/4K-bit Serial EEPROM
Name A0, A1, A2 Type Input Description Input pins for device address selection.
To configure a device address, these pins should be connected to the VCC or VSS of the device.
These pins are internally pulled down to VSS.
Ground pin.
Bi-directional data pin for the I C-bus serial data interface.
Sch
S524A40X40 Features
* are a hardware-based write protection circuit for the entire memory area and software-based write protection logic for the lower 128 bytes. Hardware-based write protection is controlled by the state of the write-protect (WP) pin. The software-based method is one-time programmable and permanent. Usin
