KBP201G, KBP2005G - SINGLE PHASE 2.0AMP GLASS PASSIVATED BRIDGE RECTIFIER

Sangdest Microelectronics

📥 Download Datasheet

KBP201G Datasheet Preview — This datasheet PDF includes multiple part numbers: KBP201G, KBP2005G. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: KBP201G, KBP2005G
Manufacturer: SangdeSTMicroelectronics ↗
File Size: 399.04 KB
Datasheet: KBP2005G-SangdestMicroelectronics.pdf
Description: SINGLE PHASE 2.0AMP GLASS PASSIVATED BRIDGE RECTIFIER
Note: This datasheet PDF includes multiple part numbers: KBP201G, KBP2005G.
Please refer to the document for exact specifications by model.

KBP201G Product details

Features

Glass passivated die construction.
Low forward voltage drop.
High current capability.
High surge current capability.
Plastic material-UL flammability 94V-0.
This is a Pb.
Free Device.
All SMC parts are traceable to the wafer lot.
Additional testing can be offered upon request Circuit Diagram Mechanical Data.
Case: KBP, molded plastic.
Terminals: plated leads solderable per MIL-STD-202, Method 208.
Polarity: as marked on case.
