STK392-040 - Thick Film Hybrid IC

Product Overview

Sanyo

📥 Download Datasheet

STK392-040 Thick Film Hybrid IC by Sanyo - Datasheet Preview — Datasheet preview – STK392-040

Datasheet Details

Part number	STK392-040
Manufacturer	Sanyo
File Size	91.58 KB
Description	Thick Film Hybrid IC
Datasheet	STK392-040 Datasheet
Additional preview pages of the STK392-040 datasheet.

Product details

Features

3 output amplifier circuits in a single package (22-pin).
High absolute maximum supply voltage (VCC max = ±50V).
Low thermal resistance (θj-c=1.8°C/W).
High temperature stability (TC max=125°C).
Separate predriver and output stage supplies.
Output stage supply switching for high-performance designs.
Pins are arranged in separate groups of inputs, supply, and outputs to reduce the adverse effects of pattern layout on characteristics.
