STK4048XI - AF Power Amplifier

Name: STK4048XI
SKU: STK4048XI-499600

Sanyo

📥 Download Datasheet

STK4048XI Datasheet Preview — Preview of STK4048XI PDF

Datasheet Details

Part number	STK4048XI
Manufacturer	Sanyo
File Size	230.47 KB
Description	AF Power Amplifier
Datasheet	STK4048XI_Sanyo.pdf

STK4048XI Product details

Description

of External Parts No.2909 5/8 STK4048XI R1, C1 Input ﬁlter circuit Used to reduce noise at high frequencies. Used to block DC current. Used to bias the input pin to zero. Affects VN stability.

Features

www. DataSheet4U. com Package Dimensions unit: mm 4051A [STK4048XI].
The use of a current mirror circuit, cascode circuit, pure complementary circuit provides low distortion (THD= 0.008%/100kHz LPF ON).
Possible to design electronic supplementary circuits (pop noise muting at the time of power ON/OFF, load short protector, thermal shutdown) Speciﬁcations Maximum Ratings at Ta = 25°C Parameter Maximum supply voltage Thermal resistance Junction temperature Operating substrate t.
