STF202-30 - USB Upstream Port Filter & TVS

Product Overview

Semtech Corporation

📥 Download Datasheet

STF202-30 USB Upstream Port Filter & TVS by Semtech Corporation - Datasheet Preview — Datasheet preview – STF202-30

Datasheet Details

Part number	STF202-30
Manufacturer	Semtech Corporation
File Size	192.74 KB
Description	USB Upstream Port Filter & TVS
Datasheet	STF202-30 Datasheet
Note	This datasheet PDF includes multiple part numbers: STF202-30, STF202-22. Please refer to the document for exact specifications by model.
Additional preview pages of the STF202-30 datasheet.

Product details

Description

The STF202 is a combination EMI filter and line termination device with integrated TVS diodes for use on upstream USB ports.

Features

Bidirectional EMI/RFI filtering and line termination.
with integrated ESD protection ESD protection for USB power (VBUS) and data lines (D+ & D-) to IEC 1000-4-2 Level 4 Filtering and termination for two USB data lines Different series resistors for impedance matching Low TVS operating voltage (5.25V) Low leakage current Small SOT-23 6L package Solid-state technology.
