LR38585

Single-chip Driver IC

LR38585 Features

* Designed for 1/3-type 270 k/320 k-pixel B/W CCD area sensors with a dual-power-supply operation

* Switchable between EIA and CCIR modes www.DataSheet4U.com

* Electronic shutter and EE control are possible

* Maximum shutter speed is selectable from approx. 1/100 000

LR38585 General Description

Single-chip Driver IC for 270 k/320 k-pixel B/W CCDs with Dual-power-supply Operation PIN CONNECTIONS 48-PIN QFP TOP VIEW The LR38585 is a CMOS single-chip driver IC which generates timing pulses for driving 270 k/320 kpixel B/W CCD area sensors with a dual-powersupply operation, synchronous pulse.
