LH28F128BFHT-PTTL75A - Flash memory

Product Overview

Sharp

Datasheet Details

Part number	LH28F128BFHT-PTTL75A
Manufacturer	Sharp
File Size	500.00 KB
Description	Flash memory
Datasheet	LH28F128BFHT-PTTL75A Datasheet
Additional preview pages of the LH28F128BFHT-PTTL75A datasheet.

Product details

Description

4 www.DataSheet4U.com PAGE 1 Electrical Specifications 19 1.1 Absolute Maximum Ratings 19 1.2 Operating Conditions 19 1.2.1 Capacitance 20 Simultaneous Operation Modes Allowed with 6 Planes 5 Memory Map 6 1.2.2 AC Input/Output Test Conditions 20 Identifier Codes and OTP Address for Read Operation 9 OTP Block Address Map for OTP Program 10 Bus Operation 11 Command Definitions 12 Functions of Block Lock and Block Lock-Down 14 Block Locking State Transitions upon Command Write 14 Block Loc

Features

Individual Block Lock and Block Lock-Down with Zero-Latency.
All blocks are locked at power-up or device reset.
Block Erase, Full Chip Erase, (Page Buffer) Word Program Lockout during Power Transitions.
Automated Erase/Program Algorithms.
3.0V Low-Power 11µs/Word (Typ. ) Programming.
9.5V No Glue Logic 9µs/Word (Typ. ) Production Programming and 0.8s Erase (Typ. ).
Cross-Compatible Command Support.
Basic Command Set.
