ST7712 - 262K Color Single-Chip TFT Controller/Driver

Product Overview

Sitronix Technology

📥 Download Datasheet

ST7712 262K Color Single-Chip TFT Controller/Driver by Sitronix Technology - Datasheet Preview — Datasheet preview – ST7712

Datasheet Details

Part number	ST7712
Manufacturer	Sitronix Technology
File Size	1.25 MB
Description	262K Color Single-Chip TFT Controller/Driver
Datasheet	ST7712 Datasheet
Additional preview pages of the ST7712 datasheet.

Product details

Features

Driver Output Circuits.
396 source output.
132 gate output On-chip Low Power Analog Circuit.
On-chip oscillator circuit.
Voltage converter generating liquid crystal driver up to 6-time scale.
Simultaneous availability of 262K color with γ-correction function On-chip Display Data RAM.
Capacity: 396 × 132 × 6 =313,632bits.
65K colors (RGB)= (565) mode.
262K colors (RGB)= (666) mode Operating Voltage Range.
Vcc: 2.4~3.3V (lo.
