DMJ3926 Silicon Beamless Schottky Diodes

Skyworks

DMJ3926 Description

DATA SHEET Silicon Beamless Schottky Diodes: Pairs and Quads Applications * Microwave MIC assembly and automated high volume manufacturing lines .
Skyworks beamless diode family is designed for a high degree of device reliability in both commercial and industrial uses.

DMJ3926 Features

* Mechanically rugged design
* Three barrier heights for optimized mixer performance
* Wide product range: series pair, ring, bridge, and eight-diode rings
* Use in ring or crossover designs in double balanced mixers
* Virtually any LO requirement can be met with choice of barrie

DMJ3926 Applications

* Microwave MIC assembly and automated high volume manufacturing lines

📥 Download Datasheet

DMJ3926 Datasheet Preview — Preview of DMJ3926 PDF

Datasheet Details

Part number: DMJ3926
Manufacturer: Skyworks
File Size: 467.01 KB
Datasheet: DMJ3926-Skyworks.pdf
Description: Silicon Beamless Schottky Diodes
