CXD1254AR CCD Camera Synchronization and Timing Signal Generator

Sony Corporation

CXD1254AR Description

CXD1254AR/AQ CCD Camera Synchronization and Timing Signal Generator .
The CXD1254AR and CXD1254AQ Ics generates the necessary synchronization and timing signals for camera systems employing CCD image sensors (ICX044, ICX.

CXD1254AR Features

* Supports color (NTSC) and black & white (EIA/CCIR) systems
* On-chip electronic shutter
* On-chip horizontal (H) driver

CXD1254AR Applications

* CCD camera systems Structure Silicon gate CMOS IC CXD1254AR 64 pin LQFP (Plastic) CXD1254AQ 64 pin QFP (Plastic) Absolute Maximum Ratings (Ta=25 °C, VSS=0 V)
* Supply voltage VSS
* 0.5 to +7.0 V
* Input voltage VSS
* 0.5 to VDD +0.5 V
* Output voltage VSS
