BAV19W - BAV21W
SURFACE MOUNT FAST SWITCHING DIODE
Features
! Fast Switching Speed ! Surface Mount Package Ideally Suited for
Automatic Insertion ! For General Purpose Switching Applications
Mechanical Data
! Case: SOD-123FL plastic body over passivated junction
! Terminals : Plated axial leads, ! solderable per MIL-STD-750,Method 2026 ! Polarity : Color band denotes cathode end ! Mounting Position : Any ! Weight:0.0007 ounce, 0.02 grams
B
C
E
D H
L
E
A
SOD-123FL Dim Min Max Typ
A 3.50 3.90 3.70 B 2.60 3.00 2.80 C 1.63 1.93 1.78 D 0.93 1.00 0.98 E 0.85 1.25 1.00 H 0.15 0.25 0.20 L 0.55 0.75 0.
