Description
Peak Pulse Power Dissipation on TL=50°C Derate above 50°C
Peak Forward Surge Current
TJ,TSTG
Operating Junction and Storage Temperature Range
Note: Mounted on 5.0mm² (.013mm thick) land areas.Value 2 15
-55 to 150
Unit Conditions
W Note
8.3ms single half sine-
A
wave superimposed on rated load (JEDEC
Method)
°C
TAIT
Features
- Low profile package.
- Built-in strain relief.
- Low inductance.
- Complete voltage range 6.8 to 51V.
- High temperature soldering guaranteed: 260°C/10 seconds at terminals.
- RoHS compliant
DO-15
Mechanical Data
Case: Epoxy: Terminals: Polarity: Weight:
JEDEC DO-15, molded plastic over passivated junction Plastic package has UL flammability classification 94V-0 Solder plated, solderable per MIL-STD-750, Method 2026 Color band denotes cathode end.
