TPA4809S

1W 3KVDC Isolated Single and Dual Output DC/DC Converters

TOPPOWER

TPA4809S Features

* RoHS compliant、CE certification Efficiency up to 81% Power density up to 0.86W/cm3 Single and dual output from a single input rail UL 94V-0 package material No heat sink required 3KVDC isolation Industry standard pinout Power sharing on output Input voltage: 24V , 48V Output voltage: 5V, 9V

TPA4809S General Description

1W 3KVDC Isolated Single and Dual Output DC/DC Converters The TPA series are miniature, isolated 1W DC/DC converters in a SIP and DIP package. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible to off.

TPA4809S Datasheet (597.71 KB)

TPA4809S Datasheet Preview — Preview of TPA4809S PDF

Datasheet Details

Part number:

TPA4809S

Manufacturer:

TOPPOWER

File Size:

597.71 KB

Description:

1w 3kvdc isolated single and dual output dc/dc converters.
