TPH0509D

2W 3KVDC Isolated Single & Dual Output DC/DC Converters

TOPPOWER

TPH0509D Features

* RoHS compliant Efficiency up to 86% Power density up to 1.44W/cm3 Operating temperature: -40ºC to 105ºC Power sharing on output Dual output from a single input rail 3KVDC isolation UL 94V-0 package material Industry standard pinout Input voltage:3.3V,5V,12V,15V, 24V, 48V Output voltage: ±5V,±

TPH0509D General Description

2W 3KVDC Isolated Single & Dual Output DC/DC Converters The TPH series are miniature, isolated 2W DC/DC converters in a SIP and DIP package. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible to offer.

TPH0509D Datasheet (593.62 KB)

TPH0509D Datasheet Preview — Preview of TPH0509D PDF

Datasheet Details

Part number:

TPH0509D

Manufacturer:

TOPPOWER

File Size:

593.62 KB

Description:

2w 3kvdc isolated single & dual output dc/dc converters.
