📥 Download Datasheet
This datasheet PDF includes multiple part numbers: SSL23, SSL22. Please refer to the document for exact specifications by model.
Datasheet Details
- Part number
- SSL23, SSL22
- Manufacturer
- TSC
- File Size
- 241.36 KB
- Datasheet
-
SSL22_TSC.pdf
- Description
-
(SSL22 - SSL24) 2.0 AMPS. Surface Mount Low VF Schottky Barrier Rectifiers
- Note
- This datasheet PDF includes multiple part numbers: SSL23, SSL22.
Please refer to the document for exact specifications by model.
SSL23 Product details
Features
- Low power loss, high efficiency.
- Ideal for automated placement.
- Guard ring for over-voltage protection.
- High surge current capability.
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC.
- Halogen-free according to IEC 61249-2-21.
