4N47A, 4N47 - Hi-Reliability Optically Coupled Isolator

4N47A Datasheet Preview — This datasheet PDF includes multiple part numbers: 4N47A, 4N47. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	4N47A, 4N47
Manufacturer	TT
File Size	331.14 KB
Description	Hi-Reliability Optically Coupled Isolator
Datasheet	4N47-TT.pdf
Note	This datasheet PDF includes multiple part numbers: 4N47A, 4N47. Please refer to the document for exact specifications by model.

4N47A Product details

Description

Each isolator in this series consists of an infrared emi ng diode and a NPN silicon phototransistor, which are mounted in a herme cally sealed TO‐78 package.

Features

 TO-78 hermetically sealed package.
 High current transfer ratio.
 1 kV electrical isolation.
 Base contact provided for conventional transistor biasing.
 TX and TXV devices processed to MIL-PRF-19500.
