2SA970 Silicon PNP Epitaxial Type Transistor

2SA970 Description

2SA970 TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT process) 2SA970 Low Noise Audio Amplifier Applications * Low noise :NF = 3dB (typ..

2SA970 Applications

* Low noise :NF = 3dB (typ. ) RG = 100 Ω, VCE =
* 6 V, IC =
* 100 μA, f = 1 kHz : NF = 0.5dB (typ. ) RG = 1 kΩ, VCE =
* 6 V, IC =
* 100 μA, f = 1 kHz
* High DC current gain: hFE = 200~700
* High breakdown voltage: VCEO =
* 120 V
* Low

📥 Download Datasheet

Preview of 2SA970 PDF
datasheet Preview Page 2 datasheet Preview Page 3
