TPD1030F Datasheet, Switch, Toshiba Semiconductor

TPD1030F Features

• Switch
• Two built-in power IC chips with a new structure combining a control block and a vertical power MOSFET (L2-π-MOS) on each chip.
• Can directly drive a power load from

PDF File Details

Part number:

TPD1030F

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

192.00kb

Download:

📄 Datasheet

Description:

2-in-1 low-side switch. Pin No. 1 2 3 4 5, 6 7, 8 Symbol Pin Description SOURCE1 IN1 SOURCE2 IN2 DRAIN2 DRAIN1 Source pin 1 Input pin 1 This pin is conn
