Description
885010 is a high-performance Bulk Acoustic Wave (BAW) notch filter designed to reject emissions in the WiFi, Bluetooth, and ISM bands, while passing both the 2.3GHz & 2.6GHz WiMAX/LTE/TD-LTE bands.
Features
- Rejects entire 2.4 GHz WiFi/BT/ISM bands Low Loss in 2502-2690 MHz bands: WiMAX/LTE/TD-LTE/Bands 7 & 38 Low Loss in 2300-2360 MHz bands: WiMAX/WCS/WiBro/Band 40/Indian 4G band Industry-leading small size: 1.7 x 1.3 x .46 mm Power Handling: +28 dBm (ave), +37.5 dBm (peak) Performance -30 to +85 ºC Ceramic chip-scale Package (CSP) Hermetic RoHS compliant, Pb-free
Functional Block Diagram
Top view
9 10
www. DataSheet. net/
8
7
6 5
1
2
3
4
General.
